SIMCom presents an ultra compact and reliable wireless module-SIM900. This is a complete Quad-band GSM/GPRS module in a SMT type and designed with a very powerful single-chip processor integrating AMR926EJ-S core, allowing you to benefit from small dimensions and cost-effective solutions.

Featuring an industry-standard interface, the SIM900 delivers GSM/GPRS 850/900/1800/1900MHz performance for voice, SMS, Data, and Fax in a small form factor and with low power consumption. With a tiny configuration of 24mm x 24mm x 3 mm, SIM900 can fit almost all the space requirements in your M2M applications, especially for slim and compact demands of design.

FEATURES:

• Quad-Band 850/ 900/ 1800/ 1900 MHz
• GPRS multi-slot class 10/8
• GPRS mobile station class B
• Compliant to GSM phase 2/2
• Class 4 (2 W @850/ 900 MHz)
• Class 1 (1 W @ 1800/1900MHz)
• SAIC (Single Antenna Interference Cancellation)support
• Control via AT commands (GSM 07.07 ,07.05 andSIMCOM enhanced AT Commands)
• SIM application toolkit
• Supply voltage range : 3.2-4.8V
• Low power consumption: 1.0mA (sleep mode&BS-PAMFRMS=9 )
